Description
The GeoMax Zenith 60 GNSS Recievers ensures precise, accurate, and hassle-free measurements. Whether working under dense canopy, in urban canyons, or on construction sites, this high-performing RTK rover provides reliable data in challenging conditions. Integrated into the world of GeoMax X-PAD software keeps you covered with intuitive workflows and easy data exchange from measuring to processing to help you get maximum results in minimum time.
GeoMax Zenith 60 Feature
Seamlessly integrated into your workflow
X-PAD Ultimate, the dedicated GeoMax field software, convinces with a perfect balance between clear structure, straight forward workflows and high functionality. Through close cooperation with key-users, it is always kept up to date.
The GeoMax software offering is completed by X-PAD Fusion. X-PAD Fusion has the versatility and flexibility to fuse all data types from both GeoMax sensors and other 3rd party sources such as drones.
Affordable price
Providing top-performing technology at an affordable price, the Zenith60 PRO GNSS receiver convinces with a remarkable performance ratio.
GeoMax Zenith 60 technical
- Calibration free IMU technology incorporated
- Resistant to electromagnetic fields
- Tilt up to 60 degrees
- Magnesium housing
- 4G/LTE support
- Hot swappable batteries
- Increased operating time
- L-band: Terrastar-C Pro correction service
- Improved initialisation time
- Reliability 99.99%
- No extra GSM antenna is necessary
- QR Code supported
- High quality components from strong and well-known suppliers and partners: Hexagon, Novatel, Lemo, SATEL
Advantages of IMU technology
- NO need to calibrate the sensor
- The pole can be tilted up to 60°
- Powered by NovAtel and Hexagon technology
GeoMax Zenith 60 Specifications
- 555 channels, dual-frequency / multi-constellation
- Support of GPS, GLONASS, BeiDou, Galileo and QZSS satellite constellations
- UHF radio module SATEL TR4+, 500mW, 1000 mW transceiver, 403–473 MHz; (optional)
- Accuracy: Static Hz/V: 3mm+1ppm/5mm+1ppm, RTK Hz/V: 8mm+1ppm/ 15mm+1ppm
- USB & Bluetooth communication
- IP68 Dust tight and withstands powerful water jets.
